The AC2435 is a compact AS-Interface digital I/O module providing four digital inputs and four digital outputs. It is designed for distributed machine automation and combines sensor acquisition with actuator control in one field device. The M12 interface provides convenient field wiring. Its IP67 construction supports installation in industrial environments. The module provides a high-density eight-channel interface for AS-i automation networks.
Product Overview
The AC2435 integrates four PNP digital inputs and four PNP outputs. It supports direct connection of sensors and actuators at the machine level. The AS-i network transfers both input and output process data. The module is designed without infrared addressing. Its compact construction provides efficient distributed I/O functionality.
I/O Performance
Four inputs collect digital sensor information. Four outputs provide actuator switching. The outputs support industrial loads and include short-circuit protection. The module supports separate actuator supply through AUX. This makes it suitable for machines with multiple local actuators.
Installation & Integration
M12 connections provide standardized field wiring. IP67 protection supports decentralized installation. The module can be located close to sensors and actuators. AS-i reduces long multi-core control cables. This supports clean and scalable machine architectures.
Diagnostics & Maintenance
Channel states can be monitored through the automation controller. AS-i network diagnostics support fault isolation. Input and output operation can be tested during commissioning. M12 connections simplify field replacement. The robust design supports regular industrial maintenance.
4 digital inputs
4 digital outputs
PNP input/output architecture
M12 connections
AS-i communication
No infrared addressing
IP67 protection
AUX actuator supply
Short-circuit protection
Distributed I/O
PLC integration
Compact field design
Packaging machinery
Conveyor systems
Assembly lines
Pneumatic systems
Material handling
Machine automation
Production equipment
Factory automation
Robotic cells
Sensor networks
Actuator control
Industrial workstations
| No. | Specification | Details |
|---|---|---|
| 1 | Product Code | AC2435 |
| 2 | Product Type | Digital I/O module |
| 3 | Inputs | 4 |
| 4 | Outputs | 4 |
| 5 | Input Circuit | PNP |
| 6 | Output Circuit | PNP |
| 7 | Input Supply | AS-i |
| 8 | Output Supply | AUX |
| 9 | Input Current Limit | 15 mA/channel |
| 10 | Input High Current | 6–10 mA |
| 11 | Input High Threshold | >11 V |
| 12 | Output Voltage | 10–30 V DC AUX |
| 13 | Output Current | Up to 2 A/channel |
| 14 | Total Output Current | Up to 4 A |
| 15 | Short-Circuit Protection | Yes |
| 16 | AS-i Version | 2.11 / 3.0 |
| 17 | AS-i Profile | S-7.0.E |
| 18 | Extended Addressing | No |
| 19 | Connection | M12 |
| 20 | Protection | IP67 |
| 21 | Ambient Temperature | -25 to 80 °C |
| 22 | Installation | Distributed field |
| 23 | Diagnostics | Network/channel status |
| 24 | Maintenance | M12 service connection |
| 25 | Application | Industrial digital I/O |
